Description
| Model | ECOSYS M5526cdw | |
|---|---|---|
| Main Function | Copy, Print, Scan, Fax | |
| Writing Method | Semiconductor Laser | |
| CPU | 800MHz | |
| Print Speed (A4) (Mono/Color) | 26/26 ppm | |
| Scanning Speed (A4) 300dpi | Simplex | 30/23 ipm |
| Duplex | 24/16 ipm | |
| Memory | Standard 512MB (Max. 1,536MB) | |
| 29 seconds | ||
| Paper Capacity | Standard | 250 sheets (Cassette) + 50 sheets (MPT) |
| Maximum | 550 sheets (Main Unit + 250 sheets PF-5110 + MPT) | |
| Paper Size | Cassette | Min. A6R – Max. A4 (Legal) |
| MPT | Min. A6R – Max. A4 (Legal) | |
| Paper Weight | Cassette | 60 – 163 g/m2 |
| MPT | 60 – 220 g/m2 | |
| Duplex Printing | Paper size: A5R – A4/Legal; Paper weight: 60 – 120 g/m2 | |
| Output Capacity | Max. 150 sheets face-down | |
| 4.3 inch Color Touch LCD Panel | ||
| Document Processor | Standard (Max. 50 sheets One-path duplex scanning Type) | |
| Dimension (W x D x H) (Main Unit) | 417mm x 429mm x 495mm | |
| Weight (Main Unit) | Approx. 26kg | |
| Power Consumption(Standard configuration) | Copy/Print Mode | 375W |
| Stand-by Mode | 41W | |
| Energy Saver | 1W | |
| Noise(ISO7779/ ISO9296) | Copy/Print Mode | 49dB(A); Quiet mode: 44dB(A) |
| Stand-by Mode | 30dB(A) | |
Copy Functions (Standard)
| Model | ECOSYS M5526cdw | |
|---|---|---|
| Copy Size | Max. A4 (Legal) – Min. A6R | |
| Resolution | 600 x 600 dpi | |
| First Copy Time (Mono/Color) | 8/10 seconds | |
| Zoom Ratio | Manual | 25% – 400% (1% per Step) |
| Pre-defined | 7R5E | |
| Multiple Copy | 1 – 999 | |
Print Functions (Standard)
| Model | ECOSYS M5526cdw | |
|---|---|---|
| Resolution | 600 x 600 dpi; 1,200 x 1,200 dpi | |
| PDL | PRESCRIBE, PCL6 (PCL-XL, PCL 5c), KPDL3 (Postscript 3 compatible), XPS, PDF Direct Print Ver. 1.7 | |
| First Print Out Time (Mono/Color) | 9.5/10.5 seconds | |
| Supported Protocol | TCP/IP, NetBEUI, FTP, Port 9100, LPR, IPP, WSD Print, Apple Bonjour, IPsec, SNMPv3, IEEE802.1x, IPP over SSL/TLS, HTTP over SSL/TLS, FTP over SSL/TLS, SMTP over SSL/TLS, POP3 over SSL/TLS, Enhanced WSD over SSL/TLS | |
| Operating System Supported | Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows XP, Windows Vista, Windows 7, Windows 8, Windows 8.1; Apple Macintosh OS X 10.5 or later; Linux | |
| Interface | USB 2.0 High Speedx1; Ethernet 10BASE-T/100BASE-TX/1000BASE-T; USB Host Interface (USB Host)x1, 802.11 b/g/n/Wireless LAN/WiFi Direct (ECOSYS M5521cdw/ ECOSYS M5526cdw only) | |
| USB Memory Printing | Standard | |
| USB Memory Printing Format | TIFF, JPEG, PDF, XPS | |
| Mobile Printing | AirPrint, Mopria, KYOCERA Mobile Print | |
Scan Functions (Standard)
| Model | ECOSYS M5526cdw | |
|---|---|---|
| Color Selection | Full Color; Grayscale; Black & White | |
| Resolution | 600dpi, 400dpi, 300dpi, 200dpi, 200x400dpi, 200x100dpi | |
| File Format | TIFF, JPEG, XPS, OpenXPS, PDF (MMR/JPG compression/High-compression PDF), PDF/A, Encrypted PDF | |
| Image Type Mode | Text, Photo, Text + Photo, Light Text/Fine Line | |
| Transmission Type | Scan to SMB; Scan to E-mail; Scan to FTP or FTP over SSL; Scan to DFS; Scan to USB; TWAIN Scan; WSD Scan, WIA | |
| Address Storage | 100 addresses (Common address list), 20 groups (Group address list) | |
Fax Functions (Standard)
| Model | ECOSYS M5526cdw |
|---|---|
| Original Size | Max. A4 (Legal) – Min. A6 |
| Coding Method | MMR, MR, MH, JBIG |
| Transmission Speed | 33.6 kpbs |
| Memory | 3.5MB |
| One Touch Dial | 100 numbers |
| Network FAX | Yes |
