Description
General
General type:
Monochrome multifunctional for A3 format
Engine speed:
Up to 32/17 pages per minute A4/A3
Warm-up time:
Approx. 18 seconds or less from power on
Power consumption:
Printing: 510 W, Stand-by: 100 W, Energy saving priority 0.5 W
Paper Handling
Input capacity:
100-sheet multi-purpose tray, 45–256 g/m²: A3, A4, A5, A6, B5, Ledger, Letter, Legal, Folio, Custom (98 x 148 to 297 x 432 mm), 2 x 500-sheet universal paper cassette, 60–163 g/m²: A3, A4, A5, B5, Ledger, Letter, Legal, Folio,
Max. input capacity with options:
4,100 sheets A4
Duplex unit:
Duplex as standard supports A5R–A3, 60–160 g/m²
Max. output capacity:
Standard 300 sheets, 250 sheets face-down (Main Tray) plus 50 sheets (standard Job Separator Tray), Max 3,200 sheets with options
Processor
Processor:
PANTHER ARM A53 1.6GHz
Fonts:
93 outline fonts (PCL), 93 fonts (KPDL 3), 8 fonts (Windows Vista), 1 Bitmap font, 45 types of one-dimensional barcodes, 1 type of two-dimensional barcode (PDF417)
Features:
Encrypted PDF Direct Print, IPP printing, e-mail printing, WSD print, secure printing via SSL, IPsec,SNMPv3, quick copy, proof and hold, private print, job storage and job management functionality
Applicable OS:
All current Windows operating systems; MAC OS X Version 10.5 or higher; Unix, Linux as well as other operating systems on request.
Copy
Max. original size: A3/Ledger
Continuous copy: 1 – 999
Zoom range: 25 – 400 in 1% steps
Preset magnification ratios: 5 Reductions/ 5 Enlargements
Image adjustments: Text + Photo, Photo, Text, Map, Printed document
Digital copy features:
Scan-once-copy-many, electronic sort, 2in1, 4in1, image repeat, page numbering, cover mode. booklet copy, interrupt copy, form overlay, margin shift, auto cassette change, Skip blank page, ID copy in Program mode
Scan
Scan functionalities:
Scan-to-email, Scan-to-FTP, Scan-to-SMB, Scan-to-USB Host, Scan-to-box, Network TWAIN, WIA, WSD scan
Scan speed:
200 ipm (300 dpi, A4, duplex, b/w, with DP-7170/7160) 200 ipm (300 dpi, A4, duplex, colour, with DP-7160/DP-7170) 100 ipm (300 dpi, A4, simplex, b/w, with DP-7170/7160) 100 ipm (300 dpi, A4, simplex, colour, with DP-7160/DP-7170)
Scan features:
Colour scan, integrated address book, Active Directory support, encrypted data transfer, multi send (e-mail, fax, SMB/FTP folder, print) at once, Blank page skip
Scan resolution:
600 x 600 dpi, 400 x 400 dpi, 300 x 300 dpi, 200 x 400 dpi, 200 x 200 dpi, 200 x 100 dpi (24 bit), 256 greyscales per colour
Max. scan size:
A3, Banner up to 1,900 mm
File type:
TIFF, PDF, PDF/A, JPEG, Open XPS, Encrypted PDF, High compression PDF, PDF/A-1a/b, PDF/A-2a/b/u
Original recognition:
Text, photo, text + photo, light text, optimised for OCR
